DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
Technical Specifications 317
General
Network Cables:
10BASE-T:
100BASE-TX:
Fiber Optic:
2-pair UTP Cat. 3,4,5 (100 m)
EIA/TIA- 568 100-ohm STP (100 m)
2-pair UTP Cat. 5 (100 m)
EIA/TIA-568 100-ohm STP (100 m)
IEC 793-2:1992
Type A1a - 50/125um multimode
Type A1b - 62.5/125um multimode
Both types use MTRJ or SC optical connector
Number of Ports: 24 x 10/100 Mbps NWay ports
2 Gigabit Ethernet (optional)
Physical and Environmental
AC inputs: 100 - 240 VAC, 50/60 Hz (internal universal
power supply)
Power
Consumptio
n:
29 watts maximum
DC fans: 2 built-in 40 x 40 x10 mm fan
Operating
Temperatur
e:
0 to 50 degrees Celsius
Storage
Temperatur
e:
-25 to 55 degrees Celsius
Humidity: Operating: 5% to 95% RH non-condensing;
Storage: 0% to 95% RH non-condensing
Dimensions: 441 mm x 207 mm x 44 mm (1U), 19 inch rack-
mount width
