D-Link DHP-W306AV User Manual

59D-Link DHP-W306AV User Manual
Section 5 - Connecting to a Wireless Network
Connect to a Wireless Network
Using Windows
®
XP
Windows
®
XP users may use the built-in wireless utility (Zero Conguration Utility). The following instructions are for
Service Pack 2 users. If you are using another company’s utility or Windows
®
2000, please refer to the user manual
of your wireless adapter for help with connecting to a wireless network. Most utilities will have a “site survey” option
similar to the Windows
®
XP utility as seen below.
Right-click on the wireless computer icon in your system tray
(lower-right corner next to the time). Select  
.
If you receive the  bubble, click
on the center of the bubble to access the utility.
or
The utility will display any available wireless networks in your
area. Click on a network (displayed using the SSID) and click
the  button.
If you get a good signal, but cannot access the Internet, check
you TCP/IP settings for your wireless adapter. Refer to the
 section in this manual for more information.

D-Link DHP-W306AV Specifications

Power

power input	240 V AC, 50/60 Hz
power saving mode	supported

Operating Environment

operating temperature	0º to 40ºC (30º to 104ºF)
operating humidity	10% to 95% non-condensing

Data Transmission

powerline data rate	200 Mbps (PHY rate)
ethernet data rate	10/100 Mbps (autonegotiation)
wireless data rate	up to 300 Mbps

Frequency and Modulation

powerline frequency band	2 MHz to 30 MHz
wireless frequency range	2.4 GHz to 2.497 GHz
powerline modulation scheme	OFDM Symbol Modulation

Weight and Dimensions

dimensions	105 x 70 x 52 mm (4.1 x 2.8 x 2.0 inches)
weight	208 g (0.46 lb)
