D-Link DSL-2640R User Manual

Configuration
Setup Wizard Step 1 : Change Password
The password used for management access of the Router can be changed now if desired.
If you prefer to keep the existing password, click on the Skip button to go to the next step
without changing the password. Change the password and click Next to set the new
password and continue or click Skip to keep the existing password.
The new menu that appears is used to select the Internet connection type. Choose your
Country from the pull-down menu. If you see your country listed, follow the instructions
beginning on the next page. If you do not see your country listed, choose Others and click
Next, skip ahead to Setup Wizard Step 2 : Internet Connection – Other Connection
Types.
D-Link DSL-2640R User Manual
15

D-Link DSL-2640R Specifications

Power

input voltage	100-120V
input current	0.4A
frequency	50-60 Hz
output voltage	12V
output current	1.2A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps

Wireless Transfer Rates

IEEE 802.11b	11, 5.5, 2, and 1 Mbps
IEEE 802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Media Interface

ADSL interface	RJ-11 connector for connection to 24/26 AWG twisted pair telephone line
LAN interface	four RJ-45 ports for 10/100BASE-T Ethernet connection
