D-Link DSL-2640R User Manual

Configuration
Setup Wizard Step 2 : Internet Connection Type – Bridge Mode
Select the specific Connection Type from the drop-down menu.
If you are instructed to change the VPI or VCI numbers, type in the correct setting in the
available entry fields—in this example no changes are needed so this setting is grayed
out. Most users will not need to change these settings. The Internet connection cannot
function if these values are incorrect.
Click Next to go to the last Setup Wizard menu.
Click the Finish button to save the configuration and restart the Router.
D-Link DSL-2640R User Manual
22

D-Link DSL-2640R Specifications

Power

input voltage	100-120V
input current	0.4A
frequency	50-60 Hz
output voltage	12V
output current	1.2A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps

Wireless Transfer Rates

IEEE 802.11b	11, 5.5, 2, and 1 Mbps
IEEE 802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Media Interface

ADSL interface	RJ-11 connector for connection to 24/26 AWG twisted pair telephone line
LAN interface	four RJ-45 ports for 10/100BASE-T Ethernet connection
