D-Link DSL-2640R User Manual

Advanced Configuration
Remote Management
Use the Remote Management menu to enable and configure remote management of the Router through the WAN interface. In addition, management access from either the LAN
or WAN side can be restricted to the Router by specifying services allowed for management.
When remote management is enabled, the options available are to either Allow All
or Deny All with the Remote Admin Inbound Filter pull-down menu. Choose the
services allowed from the LAN or WAN by checking the Enabled box for the
service in the Remote Access Control list. Click the Apply Settings button to
make the change.
D-Link DSL-2640R User Manual
48

D-Link DSL-2640R Specifications

Power

input voltage	100-120V
input current	0.4A
frequency	50-60 Hz
output voltage	12V
output current	1.2A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps

Wireless Transfer Rates

IEEE 802.11b	11, 5.5, 2, and 1 Mbps
IEEE 802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Media Interface

ADSL interface	RJ-11 connector for connection to 24/26 AWG twisted pair telephone line
LAN interface	four RJ-45 ports for 10/100BASE-T Ethernet connection
