Configuration
Manual ADSL Setup – PPPoE/PPPoA
Follow the instructions below to configure the Router to use a PPPoE or PPPoA for the Internet connection.
Most users will only need to change some or all of the settings listed under WAN
Connection Setting and PPPoE/PPPoA.
To configure a PPPoE or PPPoA type WAN connection, follow these steps:
1. Under the PPPoE/PPPoA heading, type the User Name and Password used
for your ADSL account. A typical User Name will be in the form
user1234@isp.co.uk. The Password may be assigned to you by your ISP or you
may have selected it when you set up the account with your ISP.
2. Choose the Connection Type from the pull-down menu located under the User
Name and Password entry fields. This defines both the connection protocol and
encapsulation method used for your ADSL service. The available options are
PPPoA VC-Mux, PPPoA LLC, PPPoE VC-Mux and PPPoE LLC. If you have not
been provided specific information for the Connection Type setting, leave the
default setting.
3. Leave the MTU value at the default setting (default = 1500) unless you have
specific reasons to change this (see table below for more information).
4. For time-based accounts, type an Idle Time Out in minutes. Accounts that are
not time-based will want to choose the default connection setting 0=Always ON.
5. NAT should remain Enable. If you disable NAT, you will not be able to use more
than one computer for Internet connections. NAT is enabled and disabled
system-wide, therefore if you are using multiple virtual connections, NAT will be
disabled on all connections.
6. Leave the Default Route enabled if you want to use the Router as the default
route to the Internet for your LAN. Whenever a computer on the LAN attempts to
access the Internet, the Router becomes the Internet gateway to the computer. I
