D-Link DSL-2740M User Manual

6D-Link DSL-2740M User Manual
Section 1 - Product Overview
Hardware Overview
Back Panel
1 WPS Button
Press for 5 seconds to to start the WPS process for the 2.4 GHz network and
automatically create a secure connection to a WPS client.
2 Power Button Press to power the DSL-2740M on or o.
3 Power Connector Connector for the supplied power adapter.
4 Reset Button
To reset the device to its factory default settings, press and hold the reset
button for ve seconds.
5 LAN Ports (1-4)
Connects to Ethernet devices such as computers, switches, storage (NAS)
devices, and game consoles.
6 DSL Port Connects to a DSL-enabled telephone line.
6
5
2 3 4
1

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
