D-Link DSL-2740M User Manual

50D-Link DSL-2740M User Manual
Section 3 - Conguration
LAN QoS Settings
LAN QOSQoS Setup
ADVANCED
Name: Enter a name for this QoS rule.
Priority: Select the priority to apply to the rule: Low, Medium, High.
Protocol: Select the protocol to apply the rule to: ICMP, TCP, UDP.
Source IP Range: Enter the source IP address range and subnet mask.
Source Port Range. Enter the source port range.
Destination IP
Range:
Enter the destination IP address and subnet mask.
Destination Port
Range:
Enter the destination port range.
Click the Add/Apply button when you are nished.
LAN QOS RULES CONFIGURATION
This page allows you to congure the LAN QoS Settings.
The currently dened LAN QOS rules are displayed here.
ACTIVE LAN QOS RULES

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
