D-Link DSL-2740M User Manual

73D-Link DSL-2740M User Manual
Section 3 - Conguration
Device Info
DEVICE INFODevice Info
STATUS
This page displays the current information for the DSL-2740M, such as LAN and wireless
LAN information and statistics.
GENERAL
This section displays a summary of the system settings.
INTERNET STATUS
This section displays the current Internet connection settings. If you are using a Dynamic
WAN IP address, you may renew or release it here.
IPV6
This section displays the current IPv6 connection settings. If you are using a Dynamic WAN
IP address, you may renew or release it here.
WIRELESS LAN
This section displays a summary of the wireless network settings.
LAN
This section displays a summary of the local network settings.

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
