D-Link DSL-2740M User Manual

16D-Link DSL-2740M User Manual
Section 3 - Conguration
If you selected PPPoE/PPPoA, congure the following information:
PPPoE/PPPoA
Username: Enter your ISP account username.
Password: Enter your ISP account password.
VPI: Virtual path identifier (VPI) is the virtual path between two
points in an Asynchronous Transfer Network (ATM) network. Its
valid value is between 0 and 255. Enter the correct VPI provided
by your ISP.
VCI: Virtual channel identifier (VCI) is the virtual channel between
two points in an ATM network. Its valid value is between 32 and
65535. Enter the correct VCI provided by your ISP.
Connection Type: Select the type of encapsulation your ISP uses, PPPoE LLC,
PPPoE VC-Mux, PPPoA LLC, or PPPoA VC-Mux.
Click Next to continue and proceed to step 3.
STEP 2: SELECT INTERNET CONNECTION TYPE

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
