D-Link DSL-2740M User Manual

33D-Link DSL-2740M User Manual
Section 3 - Conguration
Wireless Network Setup Wizard
Network Name (SSID): Enter a name for your wireless network.
If you selected Automatically assign a network key, click Next and proceed to Setup
Complete.
If you selected Manually assign a network key, click Next and proceed to Step 2.
STEP 1: WELCOME TO THE DLINK WIRELESS SECURITY SETUP WIZARD
Wireless Security
Password:
Enter a password for your wireless network according to the on-
screen instructions.
Click Next and proceed to Setup Complete.
STEP 2: SET YOUR WIRELESS SECURITY PASSWORD
Your wireless settings are displayed in the table.
Click Save to nish.
SETUP COMPLETE!
This section will guide you through the Wireless Network Setup Wizard.

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
