Si30-408 Field Setting on Outdoor Unit
Field Settings from Remote Controller 57
2.1 Explanation of Basic Mode
2.1.1 Setting Mode 1
* Setting No. 1, 5 and 6 are to display only current condition.
Display contents of Malfunction / In preparation / Test operation
Display contents in low noise operation
Display contents in demand operation
Normally, the system is set to "Setting
Mode 1". In other condition, press the
MODE button(BS1) once to put the
system into "Setting mode 1".
<Selection of Setting Item>
Press the SET button (BS2) to set
LED display for setting item.
• Setting items No.1,5 and 6 display
the present status only.
Refer to the sheet in the lower right
on the contents of display.
• Setting items No. 2,3 and 4 can
select the cooling / heating selection
method.
→ After setting, press the
RETURN button (BS3) to
determine the content.
Pressing the RETURN button (BS3)
puts the system into the initial setting.
No. Setting (Display) items
Example of LED display
H1P H2P H3P H4P H5P H6P H7P
1
Display of Malfunction / In
preparation / Test operation*
7
787777
2 Select cooling / heating (Individual) 7787777
3
Select cooling / heating (Batch
master)
7778777
4 Select cooling / heating (Batch slave) 7777877
5 Low noise operation 7787777
6 Demand operation 7787777
Normal
7
787777
Malfunction 7787777
In preparation / Test - RUN 7987777
Normal
7
787777
In low noise operation 7787787
* Displays
are changed
by setting
No. 2, 3 and
4.
Normal
7
787777
In demand operation 7787778
* Displays
are changed
by setting
No. 2, 3 and
4.
8: ON
7: OFF
9: Blink
