3.13 Parameters: 12-** Ethernet
3.13.1 12-0* IP Settings
12-00 IP Address Assignment
Option: Function:
Selects the IP address assignment method.
[0]
* Manual The IP address can be set in par. 12-01 IP Address.
[1] DHCP The IP address is assigned via DHCP server.
[2] BOOTP The IP address is assigned via BOOTP server.
12-01 IP Address
Range: Function:
[000.000.000.000–
255.255.255.255]
Configure the IP address of the
option. Read-only if par. 12-00 set to
DHCP or BOOTP.
12-02 Subnet Mask
Range: Function:
[000.000.000.000–
255.255.255.255]
Configure the IP subnet mask of the
option. Read-only if par. 12-00 set to
DHCP or BOOTP.
12-03 Default Gateway
Range: Function:
[000.000.000.000–
255.255.255.255]
Configure the IP default gateway of
the option. Read-only if par. 12-00 set
to DHCP or BOOTP.
12-04 DHCP Server
Range: Function:
[000.000.000.000 –
255.255.255.255]
Read only. Displays the IP address
of the found DHCP or BOOTP server.
NOTE!
A power cycle is necessary after setting the IP parameters
manually.
12-05 Lease Expires
Range: Function:
[dd:hh:mm:ss] Read only. Displays the lease time left for the
current DHCP-assigned IP address.
12-06 Name Servers
Option: Function:
IP addresses of Domain Name Servers. Can be
automatically assigned when using DHCP.
[0] Primary DNS
[1] Secondary DNS
12-07 Domain Name
Range: Function:
Blank [0–19 characters] Domain name of the attached network.
Can be automatically assigned when
using DHCP.
12-08 Host Name
Range: Function:
Blank [0–19 characters] Logical (given) name of option.
12-09 Physical Address
Range: Function:
[00:1B:08:00:00:00–
00:1B:08:FF:FF:FF]
Read only: Displays the Physical (MAC)
address of the option.
3.13.2 12-1* Eth link par
12-1* Ethernet Link Para
Option: Function:
Applies for whole par. group.
[0] Port 1
[1] Port 2
12-10 Link Status
Option: Function:
Read only. Displays the link status of the Ethernet
ports.
[0] No link
[1] Link
12-11 Link Duration
Option: Function:
Link Duration Port 1
(dd:hh:mm:ss)
Read only. Displays the duration of
the present link on each port in
dd:hh:mm:ss.
12-12 Auto Negotiation
Option: Function:
Configures Auto Negotiation of Ethernet link parameters
for each port, ON or OFF.
[0] Off Link Speed and Link Duplex can be configured in par. 12-13
and 12-14.
[1] On
Parameter Descriptions FC 300 Programming Guide
3-102 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
3
