3.17 Parameters: 16-** Data Readouts
3.17.1 16-0* General Status
16-00 Control Word
Range: Function:
0 N/A
*
[0 - 65535 N/A] View the control word sent from the
adjustable frequency drive via the serial
communication port in hex code.
16-01 Reference [Unit]
Range: Function:
0.000 Reference-
FeedbackUnit
*
[-999999.000 -
999999.000
ReferenceFeed-
backUnit]
View the present
reference value applied
on impulse or analog
basis in the unit
resulting from the
configuration selected in
1-00 Configuration Mode
(Hz, Nm or RPM).
16-02 Reference %
Range: Function:
0.0 %
*
[-200.0 - 200.0
%]
View the total reference. The total
reference is the sum of digital, analog,
preset, bus, and freeze references, plus
catch-up and slow-down.
16-03 Status Word
Range: Function:
0 N/A
*
[0 - 65535 N/A] View the status word sent from the
adjustable frequency drive via the serial
communication port in hex code.
16-05 Main Actual Value [%]
Range: Function:
0.00 %
*
[-100.00 - 100.00
%]
View the two-byte word sent with
the status word to the bus master
reporting the main actual value.
16-09 Custom Readout
Range: Function:
0.00 CustomRea-
doutUnit
*
[0.00 - 0.00
CustomRea-
doutUnit]
View the value of custom
readout from 0-30 Unit for
User-defined Readout to
0-32 Custom Readout Max
Value
3.17.2 16-1* Motor Status
16-10 Power [kW]
Range: Function:
0.00
kW
*
[0.00 -
10000.00
kW]
Displays motor power in kW. The value
shown is calculated on the basis of the
actual motor voltage and motor current.
The value is filtered, and therefore approx.
30 ms may pass from when an input value
changes to when the data readout values
change. The resolution of readout value on
serial communication bus is in 10 W steps.
16-11 Power [hp]
Range: Function:
0.00
hp
*
[0.00 -
10000.00 hp]
View the motor power in HP. The value
shown is calculated on the basis of the
actual motor voltage and motor current.
The value is filtered, and therefore approx-
imately 30 ms may pass from when an
input value changes to when the data
readout values change.
16-12 Motor voltage
Range: Function:
0.0 V
*
[0.0 - 6000.0 V] View the motor voltage, a calculated
value used for controlling the motor.
16-13 Frequency
Range: Function:
0.0 Hz
*
[0.0 - 6500.0 Hz] View the motor frequency, without
resonance dampening.
16-14 Motor Current
Range: Function:
0.00 A
*
[0.00 -
10000.00 A]
View the motor current measured as a
mean value, IRMS. The value is filtered,
and thus approximately 30 ms may pass
from when an input value changes to
when the data readout values change.
16-15 Frequency [%]
Range: Function:
0.00 %
*
[-100.00 -
100.00 %]
View a two-byte word reporting the actual
motor frequency (without resonance
dampening) as a percentage (scale 0000–
4000 Hex) of 4-19 Max Output Frequency.
Set 9-16 PCD Read Configuration index 1 to
send it with the status word instead of the
MAV.
Parameter Descriptions FC 300 Programming Guide
