4 Product Overview
4.1 VLT® High-power Drives
The Danfoss VLT
®
drives described in this manual are available as free-standing, wall-mounted, or cabinet-mounted units.
Each VLT
®
drive is congurable, compatible, and eciency-optimized for all standard motor types, which avoids the
restrictions of motor-drive package deals. These drives come in 2 front-end congurations: 6-pulse and 12-pulse.
Benets of VLT
®
6-pulse drives
•
Available in various enclosure sizes and protection ratings.
•
98% eciency reduces operating costs.
•
Unique back-channel cooling design reduces the need for more cooling equipment, resulting in lower installation
and recurring costs.
•
Lower power consumption for control room cooling equipment.
•
Reduced ownership costs.
•
Consistent user interface across the entire range of Danfoss drives.
•
Application-oriented start-up wizards.
•
Multi-language user interface.
Benets of VLT
®
12-pulse drives
The VLT
®
12-pulse is a high
eciency AC drive that provides harmonic reduction without adding capacitive or inductive
components, which often require network analysis to avoid potential system resonance problems. The 12-pulse is built with
the same modular design as the popular 6-pulse VLT
®
drive. For more harmonic reduction methods, see the VLT
®
Advanced
Harmonic Filter AHF 005/AHF 010 Design Guide.
The 12-pulse drives provide the same benets as the 6-pulse drives in addition to being:
•
Robust and highly stable in all network and operating conditions.
•
Ideal for applications where stepping down from medium voltage is required or where isolation from the grid is
needed.
•
Excellent input transient immunity.
4.2
Enclosure Size by Power Rating
kW
1)
Hp
1)
Available enclosures
6-pulse 12-pulse
315 450 – F8–F9
355 500 E1–E2 F8–F9
400 550 E1–E2 F8–F9
450 600 E1–E2 F8–F9
500 650 F1–F3 F10–F11
560 750 F1–F3 F10–F11
630 900 F1–F3 F10–F11
710 1000 F1–F3 F10–F11
800 1200 F2–F4 F12–F13
1000 1350 F2–F4 F12–F13
Table 4.1 Enclosure Power Ratings, 380–480 V
1) All power ratings are taken at normal overload.
Output is measured at 400 V (kW) and 460 V (hp).
kW
1)
Hp
1)
Available enclosures
6-pulse 12-pulse
450 450 E1–E2 F8–F9
500 500 E1–E2 F8–F9
560 600 E1–E2 F8–F9
630 650 E1–E2 F8–F9
710 750 F1–F3 F10–F11
800 950 F1–F3 F10–F11
900 1050 F1–F3 F10–F11
1000 1150 F2–F4 F12–F13
1200 1350 F2–F4 F12–F13
1400 1550 F2–F4 F12–F13
Table 4.2 Enclosure Power Ratings, 525–690 V
1) All power ratings are taken at normal overload.
Output is measured at 690 V (kW) and 575 V (hp).
