8.2
E2 Exterior and T
erminal Dimensions
8.2.1
E2
Exterior
Dimensions
130BF329.10
585 (23.0)
1547
(60.9)
538
(21.2)
498 (19.5)
Illustration
8.10
Front,
Side,
and
Door
Clearanc
e
Dimensions
for
E2
Exterior and T
erminal Dimen...
Design Guide
MG16C302
Danfoss A/S © 11/2017 All rights reserved.
75
8
8
76
78
