Ordering Options for All VLT
®
HVAC Drive FC 102 Enclosures
Description Pos Possible option
A options 29–30 AX: No A option
A0: VLT
®
PROFIBUS DP V1 MCA 101
A4: VLT
®
DeviceNet MCA 104
AG: VLT
®
LonWorks MCA 108
AJ: VLT
®
BACnet MCA 109
AK: VLT
®
BACnet/IP MCA 125
AL: VLT
®
PROFINET MCA 120
AN: VLT
®
EtherNet/IP MCA 121
AQ: VLT
®
POWERLINK MCA 122
B options 31–32 BX: No option
B0: VLT
®
Analog I/O Option MCB 109
B2: VLT
®
PTC Thermistor Card MCB 112
B4: VLT
®
Sensor Input Option MCB 114
BK: VLT
®
General Purpose I/O Module MCB 101
BP: VLT
®
Relay Card MCB 105
C0/ E0 options 33–34 CX: No option
C1 options/ A/B in C option adapter 35 X: No option
R: VLT
®
Extended Relay Card MCB 113
C option software/
E1 options
36–37 XX: Standard controller
D options 38–39 DX: No option
D0: VLT
®
24 V DC Supply MCB 107
Table 13.5 Ordering Type Code for FC 102 Options
13.2
Ordering Numbers for Options/Kits
13.2.1 Ordering Numbers for D Option: 24 V Back-up Supply
Description Ordering number
Uncoated Coated
VLT
®
24 V DC Supply MCB 107
130B1108 130B1208
Table 13.6 Ordering Numbers for D Option
13.2.2 Ordering Numbers for Software Options
Description Ordering number
VLT
®
MCT 10 Set-up Software - 1 user.
130B1000
VLT
®
MCT 10 Set-up Software - 5 users.
130B1001
VLT
®
MCT 10 Set-up Software - 10 users.
130B1002
VLT
®
MCT 10 Set-up Software - 25 users.
130B1003
VLT
®
MCT 10 Set-up Software - 50 users.
130B1004
VLT
®
MCT 10 Set-up Software - 100 users.
130B1005
VLT
®
MCT 10 Set-up Software - unlimited users.
130B1006
Table 13.7 Ordering Numbers for Software Options
