3.7.5 Input Plate Option
This section is for the field installation of input option kits available for adjustable frequency drives in all D and E frames.
Do not attempt to remove RFI filters from input plates. Damage may occur to RFI filters if they are removed from the input plate.
NOTE!
Where RFI filters are available, there are two different types of RFI filters depending on the input plate combination and the RFI filters
interchangeable. Field installable kits in certain cases are the same for all voltages.
380–480 V
380–500 V
Fuses Disconnect Fuses RFI RFI Fuses RFI Disconnect
Fuses
D1 All D1 power sizes 176F8442 176F8450 176F8444 176F8448 176F8446
D2 All D2 power sizes 176F8443 176F8441 176F8445 176F8449 176F8447
E1 FC102/ 202: 450 hp [315
kW]
: 350 hp [250 kW]
176F0253 176F0255 176F0257 176F0258 176F0260
FC102/ 202: 500–600 HP
[355–450 kW]
: 450–550 HP [315–400
kW]
176F0254 176F0256 176F0257 176F0259 176F0262
525–690 V Fuses Disconnect Fuses RFI RFI Fuses RFI Disconnect
Fuses
D1 FC102/ 202: 60–125 HP
[45–90 kW]
FC302: 50–100 HP [37–
75 kW]
175L8829 175L8828 175L8777 NA NA
FC102/202: 150–250 HP
[110–160 kW]
FC302: 125–175 HP [90–
132 kW]
175L8442 175L8445 175L8777 NA NA
D2 All D2 power sizes 175L8827 175L8826 175L8825 NA NA
E1 FC102/202: 600–675 HP
[450–500 kW]
FC302: 500–550 HP
[355–400 kW]
176F0253 176F0255 NA NA NA
FC102/202: 750–850 HP
[560–630 kW]
FC302: 675–750 HP
[500–560 kW]
176F0254 176F0258 NA NA NA
Kit contents
- Input plate assembled
- Instruction sheet 175R5795
- Modification Label
- Disconnect handle template (units w/ line power disconnect)
VLT
®
AQUA Drive Design Guide 3 VLT AQUA Selection
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 3-53
3
