Option Name Description
[4] Fast Trip Enable the fast detection to trip the
drive. This option is related to parameter
14-17 Fast Mains Phase Loss Level and
parameter 14-18 Fast Mains Phase Loss
Min Power.
[5] Fast Warning Enable the fast detection to issue
a warning. This option is related to
parameter 14-17 Fast Mains Phase Loss
Level and parameter 14-18 Fast Mains
Phase Loss Min Power.
14-15 Kin. Back-up Trip Recovery Level
Default value: Size related Parameter type: Range (0.000–500.000
ReferenceFeedbackUnit)
Setup: All setups Conversion index: -3
Data type: Uint32 Change during operation: True
This parameter specifies the kinetic back-up trip recovery level.
14-17 Fast Mains Phase Loss Level
Default value: 300% Parameter type: Range (0–1000%)
Setup: 1 setup Conversion index: 0
Data type: Uint16 Change during operation: True
Set this parameter to a lower value makes the detection more sensitive. Set this parameter to a higher value is opposite. This parameter is
only active when parameter 14-12 Response to Mains Imbalance selects option [4] Fast Trip or [5] Fast Warning.
14-18 Fast Mains Phase Loss Min Power
Default value: 10% Parameter type: Range (0–100%)
Setup: 1 setup Conversion index: 0
Data type: Uint16 Change during operation: True
The fast detection does not activate if the actual power is lower than the percentage of parameter 14-18 Fast Mains Phase Loss Min
Power x P
M, N
. This parameter is only active when parameter 14-12 Response to Mains Imbalance selects option [4] Fast Trip or [5] Fast
Warning.
4.13.3 14-2* Reset Functions
Parameters for configuring auto reset handling, special trip handling, and control card self-test, or initialization.
14-20 Reset Mode
Default value: [0] Manual reset Parameter type: Option
Setup: All setups Conversion index: –
236 | Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507
Programming Guide | VLT® AutomationDrive FC 360
