DataCard SD460 User Manual

XPS Card Printer Driver User’s Guide 83
Use a User-Defined Topcoat Bitmap
User-defined bitmaps allow you to apply topcoat to a card in custom patterns or shapes when the
predefined blocking areas and escapes are not sufficient. The bitmap files are installed as part of
the Card Printer Driver Installation in the C:\CardPrinter folder. If you previously used an older-
generation desktop printer, the bitmap files may already be on your PC.
The topcoat bitmap used depends on the card side and orientation you specify.
Side Orientation Bitmap File
1Portrait CRDPortTopcoatFront.bmp
2 Portrait CRDPortTopcoatBack.bmp
1 Landscape CRDLandTopcoatFront.bmp
2 Landscape CRDLandTopcoatBack.bmp
If the bitmap files are already installed on your computer, a new driver installation or
update does not overwrite the existing files.

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
