What to do if DataCard SD460 does not install or print when connected to a remote network via VPN?
If your DataCard Printer doesn't install or print while your PC is connected to a remote network using VPN Client software, you can either configure your VPN software to allow local network connections or disconnect the VPN Client software from the network.
Why is my DataCard SD460 Printer not installing when the USB cable is already connected?
When installing a DataCard Printer on a PC via USB for the first time, the installation must be initiated from the driver CD or the downloaded Card Printer Driver. Connect the USB cable only when prompted during the installation process, not before.
What to do if DataCard SD460 Printer does not install when the USB cable is connected?
If a previous installation attempt of your DataCard Printer was unsuccessful, the Device Manager might still have an entry for the printer. Before reinstalling, remove the printer entry from the Device Manager.
What to do if I get an error message that the USB is not detected on my DataCard SD460?
If you receive an error message stating that the USB is not detected, it means the USB installer timed out before a printer was detected. Remove the Card Printer Driver from the Device Manager before reinstalling the printer.
Why does my DataCard SD460 have a temporary communication problem?
Temporary communication problems with your DataCard Printer may be due to several factors. Check the following: USB extension cables can cause communication problems. The recommended USB cable is 6-ft. (2 meters) long and rated for USB 2.0 data transmission. If you are using a USB hub, a self-powered hub is recommended.
What to do if the cable is loose on my DataCard SD460 Printer?
If the cable is loose on your DataCard Printer, reconnect the USB cable to the ports on the PC and the printer. Power the printer off, and then back on. If the PC and printer still do not communicate, restart the PC.
What to do if the data cable of my DataCard SD460 Printer is damaged or frayed?
If the data cable is damaged or frayed, power off the DataCard printer. If you have a spare cable, replace the damaged one. Otherwise, contact your service provider to order a new data cable.
What to do if the network cable is loose on my DataCard Printer?
If the network cable is loose, reconnect the data cable to the network port and the printer, ensuring it's securely snapped in. Then, restart the printer.
Why is the PC USB port not communicating with the DataCard SD460 Printer USB port?
Power management on the PC has shut down USB communication.
General| Color | Yes |
|---|---|
| Card size | 85.6 x 53.98 mm |
| Card types | Magnetic stripe (ISO 7811), PVC, Smart card |
| Print technology | Dye-sublimation/Resin Thermal transfer |
| Duplex print speed (color) | 200 card/h |
| Display | LCD |
| Certification | cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC |
| Product color | Black, Blue |
| Internal memory | 128 MB |
| Built-in barcodes | 1D, 2D |
| Total input capacity | 100 sheets |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Wi-Fi | No |
| USB version | 2.0 |
| Ethernet interface type | Fast Ethernet |
| Storage temperature (T-T) | -15 - 60 °C |
| Operating temperature (T-T) | 15 - 35 °C |
| Storage relative humidity (H-H) | 10 - 90 % |
| Operating relative humidity (H-H) | 20 - 80 % |
Weight and Dimensions| Weight | 13600 g |
|---|---|
| Dimensions (WxDxH) | 589 x 270 x 513 mm |
Lists the Windows operating systems supported by the driver.
Details the specific Datacard and Entrust Datacard printer models supported.
Explains the primary functions and tasks of the printer driver.
Describes the communication protocols and methods via a network connection.
Details the communication process when connecting the printer via USB.
Key considerations before starting the driver installation process.
Steps involved in the basic installation of the driver.
Helps determine installation needs based on usage and environment.
Prepares the PC and printer for driver installation.
Instructions for obtaining the driver from the website.
Steps to initiate the driver installation process.
Guides through the actual driver installation for USB and network.
Process for installing additional driver support items.
Provides access to printer settings and options via a dedicated window.
Displays core printer information and general settings.
Configures network sharing options for the printer.
Manages printer port configurations, including IP address setup.
Contains advanced printer settings and configuration options.
Allows adjustment of color output and printing preferences.
Sets permissions and access controls for printer usage.
Shows real-time status, port type, and printer information.
Tracks the number of cards processed and counts for different outcomes.
Displays the status and details of installed printer supplies.
Provides driver version information and copyright details.
Outlines the procedures for removing the driver from the system.
Specific steps for uninstallation when installation media is unavailable.
Covers modifications to card layout, components, and visual elements.
Details how to configure card printing settings through Windows preferences.
Guides on configuring the printer and driver for rewritable card functionality.
Explains how to incorporate UV fluorescent panels for card security.
Covers the use of special commands to control printer operations and features.
Details how to use specific fonts for formatting magnetic stripe data.
Provides solutions for common issues preventing successful driver installation.
Addresses specific problems encountered during the USB installation process.
Resolves issues that may occur during network printer installation.
Introduces advanced tools and methods for diagnosing printer problems.
Steps for installing and setting up printer sharing for Windows.
Configuration steps for the host PC to enable printer sharing.
Instructions for installing the driver on client computers for shared access.
Guides the installation of the driver on Windows Server OS.
Configures the host PC for printer sharing on Windows Server OS.
Installs the driver on client PCs for shared access on Windows Server OS.
