Datalogic Magellan 2200VS Product Reference Guide

Programming
5-216 Magellan
TM
2200VS and 2300HS
Code 128 Maximum Label Length
This feature specifies the maximum allowable length of a Code 128 label.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET CODE 128 MAXIMUM LABEL LENGTH
below. You’ll need to cover any unused bar codes on this and the fac-
ing page to ensure that the scanner reads only the bar code you
intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired maximum label length. The selectable range for
this option is 01 to 80. Pad all single digit numbers with a leading
zero to yield a two-digit entry (01-80).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET CODE 128 MAXIMUM LABEL LENGTH
NOTE
Length in this case includes function characters and data
characters, but does not include function code change or
check character. This feature applies when Code 128 Length
Control is set to variable-length decoding.
Maximum label length should be greater than or equal to min-
imum label length.

Datalogic Magellan 2200VS Specifications

General

Decoding standards	-1D + GS1 DataBar, -GS1 DataBar Expanded Stacked, -GS1 DataBar Stacked, -GS1 DataBar Stacked Omnidirectional.
Standard interfaces	USB, RS-232
Dimensions (WxDxH)	152 x 152 x 97 mm
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
