Datalogic Magellan 2200VS Product Reference Guide

B-4 Magellan
TM
2200VS and 2300HS
OEM USB Cable Pinout
Scanner
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table B-3
PIN # FUNCTION DESCRIPTION
1 +5V pullup +5V pullup
2 N/C No Connection
3 N/C No Connection
4 USB D- USB D-
5 N/C No Connection
6 USB D+ USB D+
7 N/C No Connection
8 +5V out +5V out
9 GND Signal Ground
10 N/C No Connection

Datalogic Magellan 2200VS Specifications

General

Decoding standards	-1D + GS1 DataBar, -GS1 DataBar Expanded Stacked, -GS1 DataBar Stacked, -GS1 DataBar Stacked Omnidirectional.
Standard interfaces	USB, RS-232
Dimensions (WxDxH)	152 x 152 x 97 mm
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
