Setup
12 PowerScan™ PD953X/PBT950X/PM950X
Attaching the Metal Plate to Base
Alternatively, the mount can be attached first to the base, then both can be
mounted to a wall as described above.
Figure 5. Attaching Mounting Plate to Base
Base with Mount attached
System Connections
CAUTION
Connections should always be made with power off!
The BC9xx0 cradle provides a multi-interface connector and a power supply
connector as shown:
Power Supply
Multi-Interface Connector

Datalogic PowerScan PBT950X Specifications

General

Brand	Datalogic
Model	PowerScan PBT950X
Category	Barcode Reader
Language	English
