Dell 0403X User Manual

Table 7. External ports(continued)
Description Values
○ DisplayPort 1.4a (HBR3 support) port: Up to
5120x3200 @60Hz.
○ VGA port: Up to 1920x1200 @60Hz.
● One DisplayPort 1.4a (HBR2 support) port
NOTE: The maximum resolution that is supported is up
to 4096x2304 @60Hz.
●
One HDMI 1.4b port
NOTE: The maximum resolution supported is up to
1920 x 1200 @ 60 Hz.
Media-card reader
Not supported
Power-adapter port
Not supported
Security-cable slot
● Security-cable slot (for Kensington locks)
● One Padlock ring
Internal slots
The following table lists the internal slots of your OptiPlex Small Form Factor 7020.
Table 8.
Internal slots
Description Values
Expansion
● One Half-height Gen3 PCIe x16 slot
● One Half-height Gen3 PCIe x1 slot
M.2
● One M.2 2230 slot for Wi-Fi and Bluetooth combo card
● One M.2 2230/2280 slot for solid-state drive
NOTE: To learn more about the features of different
types of M.2 cards, search in the Knowledge Base
Resource at www.dell.com/support.
SATA slots
● One SATA 2.0 slot for 2.5-inch HDD
● One SATA 3.0 slot for 2.5-inch/3.5-inch HDD and slim
optical drive
Ethernet
The following table lists the wired Ethernet Local Area Network (LAN) specifications of your OptiPlex Small Form Factor 7020.
Table 9.
Ethernet specifications
Description Values
Model number
Intel WGI219LM
Transfer rate
10/100/1000 Mbps
22 Specifications of OptiPlex Small Form Factor 7020
Restricted - Confidential

Dell 0403X Specifications

General

Brand	Dell
Model	0403X
Category	Desktop
Language	English
