Removing and installing Field Replaceable
Units (FRUs)
The replaceable components in this chapter are Field Replaceable Units (FRUs).
CAUTION: The information in this removing and installing FRU's section is intended for authorized service
technicians only.
CAUTION: To avoid any potential damage to the component or loss of data, ensure that an authorized service
technician replaces the Field Replaceable Units (FRUs).
CAUTION: Dell Technologies recommends that this set of repairs, if needed, to be conducted by trained
technical repair specialists.
CAUTION: As a reminder, your warranty does not cover damages that may occur during FRU repairs that are not
authorized by Dell Technologies.
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Power button
Removing the power button
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the front bezel.
4. Remove the 3.5-inch hard drive, if applicable.
5. Remove the disk-drive cage.
About this task
The following image indicates the location of the power button and provides a visual representation of the removal procedure.
