Tabelle 6. Memory matrix (fortgesetzt)
32 GB DDR5 16 GB 16 GB NA NA
32 GB DDR5 8 GB 8 GB 8 GB 8 GB
64 GB DDR5 32 GB 32 GB NA NA
64 GB DDR5 16 GB 16 GB 16 GB 16 GB
128 GB
DDR5
32 GB 32 GB 32 GB 32 GB
Externe Ports
In den folgenden Tabellen sind die externen Ports Ihres OptiPlex Small Form Factor Plus 7010-Systems aufgeführt.
Tabelle 7. Externe Ports
Beschreibung Werte
Netzwerkanschluss
One RJ-45 Ethernet port 10/100/1000 Mbps
USB-Ports
● One USB 3.2 Gen 2x2 (20 Gbps) Type-C port (Front)
● One USB 3.2 Gen 2 (10 Gbps) port (Front)
● One USB 2.0 (480 Mbps) port with PowerShare (Front)
● One USB 2.0 (480 Mbps) port (Front)
● One USB 3.2 Gen 2 (10 Gbps) port (Rear)
● Three USB 3.2 Gen 1 (5 Gbps) ports (Rear)
● Two USB 2.0 (480 Mbps) ports with Smart Power On
(Rear)
Audioport
● One Universal audio jack (Front)
● One Re-tasking line-out/line-in audio port (Rear)
Video-Anschluss
● One optional video port (HDMI 2.1/Displayport 1.4a
(HBR3)/VGA/USB Type-C with DisplayPort Alt mode)
(Rear)
ANMERKUNG: The maximum resolution supported by
HDMI 2.1 is up to 4096 x 2160 @60Hz
ANMERKUNG: The maximum resolution supported by
DisplayPort 1.4a (HBR3) is up to 5120 x 3200 @60Hz
ANMERKUNG: The maximum resolution supported by
VGA is up to 1920 x 1200 @60Hz
ANMERKUNG: The maximum resolution supported by
USB Type-C with DisplayPort Alt mode is up to 5120 x
3200 @60Hz
● Three DisplayPort 1.4a ports (HBR2)
Speicherkartenleser
One SD-card slot (optional)
Netzadapteranschluss
Not supported
Sicherheitskabeleinschub
● Security-cable slot (for Kensington locks)
● One Padlock ring
22 Technische Daten des OptiPlex Small Form Factor Plus 7010
