Internes Antennen-Kit
Removing the internal antenna kit
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the front bezel.
4. Remove the 2.5-inch hard drive if applicable.
5. Remove the 3.5-inch hard drive if applicable.
6. Remove the disk-drive cage.
7. Remove the wireless card if applicable.
About this task
The following image indicates the location of the internal antenna kit and provides a visual representation of the removal
procedure.
86 Entfernen und Installieren von vor Ort austauschbaren Einheiten (FRUs)
