Dell D17S005 User Manual

Steps
1. Remove the two screws (M3x3) that secure the internal antenna kits to the chassis.
2. Remove the internal antenna kits from the chassis.
3. Unroute the internal antenna kit cable from the routing guides on the chassis
4. Gently pull the internal antenna kit cable out from the hole on the chassis.
Installing the internal antenna kit
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the internal antenna kit and provides a visual representation of the installation
procedure.
Entfernen und Installieren von vor Ort austauschbaren Einheiten (FRUs)
87
