Dell D23M User Manual

Steps
1. Align the tabs on the right-side cover with the slots on the chassis
2. Rotate the right-side cover towards the chassis until it snaps into place.
Next steps
1. Install the
top cover.
2. Install the left-side cover.
3. Follow the procedure in After working inside your computer.
2.5-inch hard drive
Removing the 2.5-inch hard drive
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
About this task
The following images indicate the location of the 2.5-inch hard drive and provides a visual representation of the removal procedure.
19
