5. Install the left-side cover.
6. Follow the procedure in After working inside your computer.
Bottom cover
Removing the bottom cover
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the left-side cover.
3. Remove the top cover.
4. Remove the
right-side cover.
5. Remove the 2.5-inch hard-drive cages.
6. Remove the front bezel.
About this task
The following images indicate the location of the bottom cover and provides a visual representation of the removal procedure.
Steps
1. Place the computer on a clean and flat surface with the left side facing up.
2. Press the securing tabs to release the bottom cover from the slots on the chassis.
3. Remove the bottom cover from the chassis.
71
