Top bezel
Removing the top bezel
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the left-side cover.
3. Remove the top cover.
4. Remove the
right-side cover.
5. Remove the
wireless card.
6. Remove the front bezel.
About this task
The following images indicate the location of the top bezel and provides a visual representation of the removal procedure.
Steps
1. Remove the four screws (#6-32) that secure the top bezel to the right and left of the chassis.
2. Lift the top cover off the chassis.
69
