Diagnostics
Power status light: Indicates the power status.
Solid Amber – The computer is unable to boot to the operating system. This indicates
that the power supply or another device in the computer is failing.
Blinking Amber – The computer is unable to boot to the operating system. This
indicates that the power supply is normal but another device in the computer is failing
or not installed properly.
NOTE: See the light patterns to determine the device that is failing.
O – Computer is in hibernation or turned o.
The power status light blinks amber along with beep codes indicating failures.
For example, the power status light blinks amber two times followed by a pause, and
then blinks white three times followed by a pause. This 2,3 pattern continues until the
computer is turned o indicating the Recovery image is not found.
The following table shows dierent light patterns and what they indicate:
Table 13. System diagnostic lights
Light pattern Problem description
1 System board, BIOS corruption, or ROM error
3 System board, Chipset error, Clock failure, Gate
A20 failure, Super I/O failure, or Keyboard
controller failure
4 Memory or RAM failure
5 Coin-cell battery failure
6 GPU failure
7 CPU failure
8 Display failure
3,6 BIOS recovery image not found
