Removing the power-button
board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-F35C996A-766A-42C4-AF15-BDAAFABE98EB
Status Released
Prerequisites
1 Remove the back cover.
2 Remove the stand.
3 Remove the inner frame.
Identifier GUID-0529F3FF-B349-427A-BA7C-8805F4692DE5
Status Released
Procedure
NOTE: Note the routing of the cable as you remove it so that you can
reroute it correctly after you replace the power-button board.
1 Open the latch and disconnect the power-button board cable (0SDC1) from the
power-button board.
2 Remove the two screws (M2x3.5) that secures the power-button board to
middle frame.
