Identifier GUID-843C6FE2-25D0-48C6-8EB2-9829A89CC1C8
Status Released
Replacing the subwoofer
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-BE616652-3985-4843-8F35-549F91910D72
Status Released
Procedure
1 Align the screw holes on the subwoofer with the screw holes on the middle
frame.
2 Replace the four screws (Washer type M3x4) that secure the subwoofer to the
middle frame.
3 Route the subwoofer cable (WOOFC1) through the routing guides on middle
frame and connect it to the system board.
Identifier GUID-EB349C56-69A8-4386-A37B-EB408439BE62
Status Released
Post-requisites
1 Replace the system-board shield.
2 Replace the back cover.
69
