Identifier GUID-FAA962E5-AD4D-4E85-BCA3-D99993D9AFD2
Status Released
Removing the fan
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-80B6901A-84B9-4E89-AECE-A1BD484B2AEF
Status Released
Prerequisites
1 Remove the back cover.
2 Remove the system-board shield.
Identifier GUID-C794653C-5FEF-4E2A-930E-906EB4783424
Status Released
Procedure
1 Disconnect the fan-power cable (FAN_SYS) from the system board.
2 Remove the fan-power cable (FAN_SYS) from the routing guides.
3 Remove the three screws (M3x5) that secure the fan to the middle frame.
61
