Replacing the I/O bracket
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-987AC29C-D294-41DC-B6AF-C2212B5B8DF3
Status Released
Procedure
1 Align the screw holes on the I/O bracket with the screw holes on the middle
frame.
2 Replace the nine screws (M3x5) that secure the I/O bracket to the middle
frame.
Identifier GUID-FC905C12-5D10-4857-AB3A-4AD62CEE2D88
Status Released
Post-requisites
1 Replace the system-board shield.
2 Replace the inner frame.
3 Replace the stand.
4 Replace the back cover.
