Replacing the microphones
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-4FEB7BCD-F2C2-4AC2-8895-63756A61115C
Status Released
Procedure
1 Using the alignment post, place the microphone modules (4) into their respective
slots on the middle frame.
2 Replace the four screws (M2x4) that secures the microphone module to the
middle frame.
3 Connect the microphones cable (DMIC1) to the microphone modules (4).
Identifier GUID-5BE3AE14-06F3-4D93-8158-E706F91E6665
Status Released
Post-requisites
1 Replace the inner frame.
2 Replace the stand.
3 Replace the back cover.
41
