Replacing the power-button
board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-87244667-768A-44CE-B1F8-622A575E5C4B
Status Released
Procedure
1 Connect the power-button board cable (0SDC1) to the power-button board.
2 Using the alignment post, place the power-button board into the slots on the
middle frame.
3 Align the screw holes on power-button board to the screw holes on middle
frame.
4 Replace the two screws (M2x3.5) that secures the power-button board to
middle frame.
Identifier GUID-5BE3AE14-06F3-4D93-8158-E706F91E6665
Status Released
Post-requisites
1 Replace the inner frame.
2 Replace the stand.
3 Replace the back cover.
