Removing the microphones
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-F35C996A-766A-42C4-AF15-BDAAFABE98EB
Status Released
Prerequisites
1 Remove the back cover.
2 Remove the stand.
3 Remove the inner frame.
Identifier GUID-C7B7E46C-E335-4B3B-9E0E-4AF6C22E33C5
Status Released
Procedure
1 Disconnect the microphones cable (DMIC1) from the microphone modules (4).
2 Remove the four screws (M2x4) that secure the microphone module to the
middle frame.
39
To Next Page
