Identifier GUID-40DC76F7-B3EC-450A-848E-632D68C352E2
Status Released
Replacing the speakers
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-69BB84A3-C667-4201-98E5-A71B89E4C12A
Status Released
Procedure
1 Using the alignment posts and rubber grommets on the middle frame, place the
speakers on the middle frame.
2 Route the speaker cable (SPEAKER) through the routing guides on middle
frame.
3 Connect the speaker cable (SPEAKER) to the system board.
Identifier GUID-FC905C12-5D10-4857-AB3A-4AD62CEE2D88
Status Released
Post-requisites
1 Replace the system-board shield.
2 Replace the inner frame.
3 Replace the stand.
4 Replace the back cover.
66
