Removing the subwoofer
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-E9F75395-8D8F-47EE-8EBF-2190420E483A
Status Released
Prerequisites
1 Remove the back cover.
2 Remove the system-board shield.
Identifier GUID-6567F1A9-396C-4F48-A6EE-60CC7A581C93
Status Released
Procedure
1 Disconnect the subwoofer cable (WOOFC1) from the system board.
2 Remove the subwoofer cable (WOOFC1) from the routing guides on the middle
frame.
3 Remove the four screws (Washer type M3x4) that secure the subwoofer to the
middle frame.
