Dell PowerEdge T30 User Manual

Item Indicator, Button, or Connector Icon Description
6 USB 2.0 port (2) Use the USB 2.0 port to connect USB devices to the system.
7 Display ports (2) Use the Display ports to connect other external display
devices to the system.
8 HDMI port Use the HDMI (High-Definition Multimedia Interface)
connector to transfer video data and compressed or
uncompressed digital audio data to a compatible computer
monitor or video projector.
9 USB 3.0 port (4) Use the USB 3.0 port to connect USB devices to the system.
10 Line-out connector Use the Line-out connector to connect the input of an audio
device to the system.
11 Line-in or microphone connector Use the Line-in or Microphone connector to connect other
input audio devices to the system.
12 Expansion card slots (4) Use the Expansion card slots to connect up to three full-
height PCIe expansion cards and one full-height PCI
expansion card.
13 Serial port Use the Serial connector to connect a serial device to the
system.
14 Ethernet port (NIC) One integrated 10/100/1000 Mbps Ethernet port. Use this
port to connect the system to the network.
15 Security-cable slot Allows you to connect a cable lock to the system.
16 Padlock ring Allows you to lock the system cover.
Diagnostic Indicators
The diagnostic indicators on the system indicate operation and error status.
Diagnostic indicators on the front panel
NOTE
: No diagnostic indicators are lit when the system is turned off. To start the system, plug it into a working power source
and press the power button.
Table 4. Diagnostic indicators on the front panel
Icon Description Condition Corrective action
Hard-drive indicator The indicator flashes amber if
there is a hard-drive error.
Check the hard drive. If the
problem persists, see the
Troubleshooting hard drive
section or the Getting help
section.
Power-on indicator The indicator flashes amber and
white if there is a component
failure.
This is due to component failure
in the system. For more
information, see the Power on
LED indicator codes section. If
12 Dell PowerEdge T30 system overview

Dell PowerEdge T30 Specifications

General

Bus type	DMI3
Stepping	R0
Scalability	1S
Processor code	SR2DC
Processor cache	3 MB
Processor cores	2
Processor model	G4400
System bus rate	8 GT/s
Processor family	Intel Pentium G
Processor series	Intel Pentium G4400 series for Desktop
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C236
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	SSE4.1, SSE4.2
Thermal Design Power (TDP)	47, 54 W
Number of processors installed	1
Thermal solution specification	PCG 2015C
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1866, 1333, 2133, 1600 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	- \
HDD interface	-
Optical drive type	No
Total storage capacity	1000 GB
Maximum storage capacity	- TB
Memory slots	4
Internal memory	4 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
PCI Express x4 slots	7
PCI Express slots version	3.0
Compatible operating systems	- Microsoft Windows Server 2012; 2012 R2; 2016 - Red Hat Enterprise Linux - Ubuntu Server 14.04/16.04
Chassis type	Mini Tower
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 35000 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
On-board graphics card ID	0x1902
On-board graphics card model	Intel® HD Graphics 510
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Number of displays supported (on-board graphics)	3
Processor ARK ID	88179
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	454 mm
Width	175 mm
Height	360 mm
Weight	11700 g
