7 In the left pane, select TPM 1.2 security.
NOTE: Ensure that the Clear checkbox is grayed out and that the TPM 1.2 security is Disabled.
8 Set the TPM 1.2 security to Enabled.
9 Click OK to apply the setting.
10 In the folder that has the TPM Update Program, double-click on the Dell TPM 1.2 Update Utility. At the TPM Update Program
windows prompt click
OK.
11 In the Confirm TPM Replacement window, click OK to start the TPM update.
The system will automatically restart.
12 The POST screen displays the update progress.
13 After the update process is complete the following message appears: Firmware Update successfully. Rebooting your system. The
system reboots after the update has completed successfully.
14 Boot to the OS, in an elevated PowerShell window, execute the following command: Enable-TPMAutoProvisioning and press
Enter.
Ensure that AutoProvisioning is enabled.
15 To access the Trusted Platform Module Management on Local Computer, in the Run window, type tpm.msc and click OK.
16 In the Trusted Platform Module Management on Local Computer window, ensure that the Specification Version: 1.2 is displayed in
the
TPM Manufacturer Information section.
17 In the Actions pane, click Prepare the TPM.
The Manage the TPM security hardware window opens. Wait till the TPM is ready message appears.
18 Close the Manage the TPM security hardware window.
The status section now indicates that the TPM is ready for use.
Configuring TPM Bitlocker key
Prerequisites
1 Ensure that you have a supported Microsoft Windows Server Operating System installed on your system.
2 Ensure that you have TPM version 2.0 installed on your system.
3 Log in as an Administrator.
Steps
1 To access the Trusted Platform Module Management on Local Computer, in the Run window, type tpm.msc and click OK.
2 In the Trusted Platform Module Management on Local Computer window, ensure that the Specification Version: 2.0 in the TPM
Manufacturer Information section.
3 In the Actions pane, click Prepare the TPM.
The Manage the TPM security hardware opens. Wait till the TPM is ready message appears.
4 From the Windows Control Panel open Bitlocker Drive Encryption.
5 In the Bitlocker Drive Encryption window, select Save to a file or Print the recovery key and click next.
6 After the process is complete, shut down the system.
7 Install the new system board that has TPM1.2 (FW_5.81.0.0).
8 Boot to the operating system.
9 From the Windows Control Panel open the Bitlocker Drive Encryption.
10 To start the encryption on the BitLocker Drive Encryption page, click Turn On BitLocker on the volume that the operating system is
installed on.
NOTE
: If the TPM is not initialized, you see the Initialize TPM Security Hardware wizard. Follow the instruction on the
screen to initialize the TPM and restart your system.
NOTE: After the encryption is completed, you will need to provide the Bitlocker key every time the system starts up.
11 To check the TPM status, access the Trusted Platform Module Management on Local Computer, in the Run window, type
tpm.msc and click OK.
System Setup
35

Dell PowerEdge T30 Specifications

General

Bus type	DMI3
Stepping	R0
Scalability	1S
Processor code	SR2DC
Processor cache	3 MB
Processor cores	2
Processor model	G4400
System bus rate	8 GT/s
Processor family	Intel Pentium G
Processor series	Intel Pentium G4400 series for Desktop
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C236
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	SSE4.1, SSE4.2
Thermal Design Power (TDP)	47, 54 W
Number of processors installed	1
Thermal solution specification	PCG 2015C
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1866, 1333, 2133, 1600 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	- \
HDD interface	-
Optical drive type	No
Total storage capacity	1000 GB
Maximum storage capacity	- TB
Memory slots	4
Internal memory	4 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
PCI Express x4 slots	7
PCI Express slots version	3.0
Compatible operating systems	- Microsoft Windows Server 2012; 2012 R2; 2016 - Red Hat Enterprise Linux - Ubuntu Server 14.04/16.04
Chassis type	Mini Tower
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 35000 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
On-board graphics card ID	0x1902
On-board graphics card model	Intel® HD Graphics 510
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Number of displays supported (on-board graphics)	3
Processor ARK ID	88179
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	454 mm
Width	175 mm
Height	360 mm
Weight	11700 g
