Dell PowerEdge T30 User Manual

Amber LED blinking scheme — The pattern is 2 or 3 blinks followed by a short pause then x number of blinks up to 7. The repeated
pattern has a long pause inserted in the middle. For example 2, 4 = 2 amber blinks followed by a short pause, and then 4 amber blinks
followed by long pause. Then, the pattern is repeated.
Table 6. Power on LED system state indicator codes
Amber LED state White LED state Description
off off system is OFF
off blinking system is in sleep state
blinking off power supply unit (PSU) failure
steady off PSU is working but failed to fetch code
off steady system is ON
Power on LED system diagnostics indicator codes
Amber LED blinking scheme — The pattern is 2 or 3 blinks followed by a short pause then x number of blinks up to 7. The same pattern is
repeated after a long pause. For example 3, 5 = 3 amber blinks followed by a short pause, and then 5 amber blinks followed by long pause.
Then, the pattern is repeated.
Table 7. Power on LED system diagnostics indicator codes
Amber LED state Description
2, 1 system board failure
2, 2 system board, PSU or PSU cabling failure
2, 3 system board, memory or CPU failure
2, 4 coin cell battery failure
2, 5 corrupt BIOS
2, 6 CPU configuration failure or CPU failure
2, 7 memory modules are detected, but there is a memory failure
3, 1 possible peripheral card or system board failure
3, 2 possible USB failure
3, 3 no memory modules are detected
3, 4 possible system board error
3, 5 memory modules are detected, but a memory configuration or compatibility error
3, 6 possible system board resource and/or hardware failure
3, 7 some other device failure with messages on screen
Power indicator codes for power supply unit
To perform a quick health check on the non-redundant power supply unit (PSU) of the system, press the self-diagnostic button.
14
Dell PowerEdge T30 system overview

Dell PowerEdge T30 Specifications

General

Bus type	DMI3
Stepping	R0
Scalability	1S
Processor code	SR2DC
Processor cache	3 MB
Processor cores	2
Processor model	G4400
System bus rate	8 GT/s
Processor family	Intel Pentium G
Processor series	Intel Pentium G4400 series for Desktop
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C236
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	SSE4.1, SSE4.2
Thermal Design Power (TDP)	47, 54 W
Number of processors installed	1
Thermal solution specification	PCG 2015C
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1866, 1333, 2133, 1600 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	- \
HDD interface	-
Optical drive type	No
Total storage capacity	1000 GB
Maximum storage capacity	- TB
Memory slots	4
Internal memory	4 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
PCI Express x4 slots	7
PCI Express slots version	3.0
Compatible operating systems	- Microsoft Windows Server 2012; 2012 R2; 2016 - Red Hat Enterprise Linux - Ubuntu Server 14.04/16.04
Chassis type	Mini Tower
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 35000 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
On-board graphics card ID	0x1902
On-board graphics card model	Intel® HD Graphics 510
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Number of displays supported (on-board graphics)	3
Processor ARK ID	88179
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	454 mm
Width	175 mm
Height	360 mm
Weight	11700 g
