Dell PowerEdge T30 User Manual

12 Click Run to install the updated BIOS settings on your system.
Follow the instructions on the screen.
Next steps
NOTE: Dell recommends not to update the BIOS version for more than 3 revisions. For example, if you want to update the BIOS
from 1.0 to 7.0, then install version 4.0 first and then install version 7.0.
Related links
Locating Service Tag of your system
BIOS recovery
BIOS recovery using USB key
Prerequisites
1 Ensure that you have the file type extensions visible in the operating system.
2 Ensure that you have downloaded the latest BIOS from the Dell support site and save it on your system.
Steps
1 Browse to the location of the downloaded BIOS update executable (.exe) file.
2 Rename the file to BIOS_IMG.rcv.
For example, if the file name is PowerEdge_T30_0.0.5.exe, rename it to BIOS_IMG.rcv
3 Copy the BIOS_IMG.rcv file to the root directory of the USB key.
4 If not plugged in, plug in the USB key, restart the system, press F2 to enter the System Setup, and then press power button to shut
down the system.
5 Start the system.
6 While the system is starting up, press the Ctrl+Esc keys while holding the power button until the BIOS Recovery Menu dialog box is
displayed.
7 Click Continue to start the BIOS recovery process.
NOTE
: Ensure that the Recovery BIOS option is selected in the BIOS Recovery Menu dialog box.
Trusted Platform Module specification
The Dell PowerEdge T30 supports upgrading the Trusted Platform Module (TPM) from version 1.2 to version 2.0 or downgrading from
version 2.0 to version 1.2.
NOTE
: The option to upgrade the TPM is supported only in the Microsoft Windows operating system environment.
NOTE: For more information about initializing the TPM using Bitlocker, see http://technet.microsoft.com/en-us/library/
cc753140.aspx.
Upgrading Trusted Platform Module to version 2.0
Prerequisites
1 Ensure that the Dell TPM 2.0 Update Utility is downloaded and is available to upgrade the TPM version from 1.2 to 2.0.
NOTE
: The TPM update file is available in the Security section of the driver and downloads of section for the system.
About this task
To upgrade the Trusted Platform Module (TPM) from version 1.2 to version 2.0, follow the steps:
System Setup
33

Dell PowerEdge T30 Specifications

General

Bus type	DMI3
Stepping	R0
Scalability	1S
Processor code	SR2DC
Processor cache	3 MB
Processor cores	2
Processor model	G4400
System bus rate	8 GT/s
Processor family	Intel Pentium G
Processor series	Intel Pentium G4400 series for Desktop
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C236
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	SSE4.1, SSE4.2
Thermal Design Power (TDP)	47, 54 W
Number of processors installed	1
Thermal solution specification	PCG 2015C
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1866, 1333, 2133, 1600 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	- \
HDD interface	-
Optical drive type	No
Total storage capacity	1000 GB
Maximum storage capacity	- TB
Memory slots	4
Internal memory	4 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
PCI Express x4 slots	7
PCI Express slots version	3.0
Compatible operating systems	- Microsoft Windows Server 2012; 2012 R2; 2016 - Red Hat Enterprise Linux - Ubuntu Server 14.04/16.04
Chassis type	Mini Tower
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 35000 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
On-board graphics card ID	0x1902
On-board graphics card model	Intel® HD Graphics 510
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Number of displays supported (on-board graphics)	3
Processor ARK ID	88179
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	454 mm
Width	175 mm
Height	360 mm
Weight	11700 g
