Delta AH Series Hardware Manual

Chapter 4 Installation and Wiring
4-23
4
_
4.5.4 Power Consumption
Products Model name Internal power consumption External power consumption
AH Motion CPU
AHxxEMC-5A 4 W -
Motion control
backplane
AHBP03M2-5A 1.2 W -
AHBP05M2-5A 1.2 W
Motion control module
AH02HC-5A 2.4 W -
AH04HC-5A 2.4 W -
AH05PM-5A 2.7 W -
AH10PM-5A 2.7 W -
AH15PM-5A 2.7 W -
AH20MC-5A 3 W -
Digital I/O module
AH16AM10N-5A 0.1 W 1.9 W
AH16AM30N-5A 0.1 W -
AH16AN01P-5A 0.2 W 0.4 W
AH16AN01R-5A 2.1 W -
AH16AN01S-5A 0.6 W -
AH16AN01T-5A 0.2 W 0.4 W
AH16AP11P-5A 0.2 W 0.2 W
AH16AP11R-5A 1.1 W -
AH16AP11T-5A 0.2 W 0.2 W
AH32AM10N-5A 0.2 W 3.8 W
AH32AM10N-5B 0.2 W 3.8 W
AH32AM10N-5C 0.2 W 3.8 W
AH32AN02P-5A 0.4 W 0.8 W
AH32AN02P-5B 0.4 W 0.8 W
AH32AN02P-5C 0.4 W 0.8 W
AH32AN02T-5A 0.4 W 0.8 W
AH32AN02T-5B 0.4 W 0.8 W
AH32AN02T-5C 0.4 W 0.8 W
AH64AM10N-5C 0.2 W 4.9 W
AH64AN02P-5C 0.6 W 1.5 W
AH64AN02T-5C 0.6 W 1.5 W
Analog I/O module
AH04AD-5A 0.35 W 1 W
AH04DA-5A 0.34 W 2.6 W
AH06XA-5A 0.34 W 1.4 W
AH08AD-5A 1.1W -
AH08DA-5A 0.36W 4.55W
AH08AD-5B 1.9 W -
