Delta RPI M6A Operation And Installation Manual

4.4. Multiple Inverter Combinations
RPI M6A/8A/10A can be used in three-phase parallel combination system.
In this application, inverter may be parallel connected to a same AC grid.
Please refer to Figure 4-6.
Figure 4-6 Three-phase parallel combinations
4.4.1. Three-Phase Parallel Combination System
L1 (Grid)
L2 (Grid)
L3 (Grid)
N (Grid)
19
Wiring
