5.3.7. Active/Reactive power
A password is required to enter Active/Reactive Power page. This page
includes two kinds of function: active power control and reactive power
control. In active power control function, there are 3 control modes: Power
Limit, Power vs. Frequency, and P(V). In reactive power control function,
there are 4 control modes: Constant cosphi, cosphi(P), Constant Q, and
q(V). These modes will be introduced in next section.
Active Power Ctrl
Reactive Power Ctrl
►
Figure 5-19 Active/Reactive power page
Figure 5-20 Power Limit page
5.3.7.1. Power Limit
This control mode can reduce the output power to a percentage of inverter’s
rated power. Users can limit the output power by set the Set Point in
Power Limit page.
Power Limit
Power vs. Frequency
P(V)
►
Mode:
Set Point:
►
ON
100%
EXIT
ENT
35
Turn on/off PV inverter
To Next Page
