9.Technical Data
RPI M6A RPI M8A RPI M10A
GENERAL
Enclosure Powder coated aluminum
Operating temperature -25~60℃ , full power up to 40℃
Operating Altitude 2000m
Relative humidity 0 – 100% non-condensing.
Environmental category Outdoor, wet locations
Protection degree IP65 (Electronics)
Pollution degree Internal : lI, External : lll
Overvoltage category AC output :III, DC Input :II
Maximum backfeed current to the
array
0
Galvanic isolation NO
Safety class Class I metal enclosure with protective earth
Weight 25kg 25kg 26kg
Dimensions(W*H*D) 510 × 445 × 177mm
Connectors Weather resistant connectors
DC INPUT (Solar side)
Maximum input power 6.6kW 8.8kW 11kW
Recommended PV power
range
5.7kW–7.5kW 7.6kW–10kW 9.5kW– 12.5kW
Nominal voltage 600Vdc
Operating voltage 200Vdc – 1000Vdc
Startup voltage > 250 Vdc
Start up power 40W
MPP tracker
Parallel inputs: 1 MPP tracker
Separate inputs: 2 MPP trackers
Absolute maximum voltage 1000Vdc
49
Technical Data
